Pad printing (also called tampography) is a printing process that can transfer a 2-D image onto a 3-D object. This is accomplished using an indirect offset (gravure) printing process that involves an image being transferred from the cliché via a silicone pad onto a substrate. Pad printing is used for printing on otherwise difficult to print on products in many industries including medical, automotive, promotional, apparel, and electronic objects, as well as appliances, sports equipment and toys. It can also be used to deposit functional materials such as conductive inks, adhesives, dyes and lubricants.

Physical changes within the ink film both on the cliché and on the pad allow it to leave the etched image area in favor of adhering to the pad, and to subsequently release from the pad in favor of adhering to the substrate.

The unique properties of the silicone pad enable it to pick the image up from a flat plane and transfer it to a variety of surfaces, such as flat, cylindrical, spherical, compound angles, textures, concave, or convex surfaces.

Pads are three-dimensional objects typically molded of silicone rubber. They function as a transfer vehicle, picking up ink from the printing plate, and transferring it to the part (substrate). They vary in shape and diameter depending on the application.

There are two main shape groups: "round pads" and long narrow pads called "bar pads". Pads are also made in other shapes, called "loaf pads". Within each group there are three size categories: small, medium, and large size pads. It is also possible to engineer custom-shaped pads to meet special application requirements.
